Compressor Pressure Issue at The Arches
Emily Clarke
10 February 2026
Summary
Checked the compressor unit and associated components due to pressure holding issue. Temporary fixes applied and monitoring suggested.
Areas Inspected
Compressor unit
OKChecked and no issues found, but client is monitoring the unit.
Pressure vessels
OKInspected and found to be functioning properly.
Air receivers
OKInspected and found to be functioning properly.
Drain valve
INTERVENTION REQUIRED- Leaking drain valve
Drain valve was leaking; isolated and purged system as a temporary fix.
Filters
INTERVENTION REQUIRED- Saturated filters
Filters were saturated and need to be replaced; temporary solution applied.
Actions Done On Site
- Checked compressor unit, pressure vessels, and air receivers
- Found leaking drain valve and isolated it
- Purged system
- Applied temporary fix for valve
- Sent a quote for valve replacement and filter service kit
Actions for Service Provider
- Quote for auto drain valve replacement
- Quote for service kit for inline filters
Actions for Client
- Monitor compressor unit for any changes
Quote Required
Replacement and servicing of parts.
| Item | Quantity | Priority |
|---|---|---|
| Replacement of auto drain valve | 1 | Medium |
| Service kit for inline filters | 1 | Medium |
Invoice Items
Service rendered and parts used.
| Item | Quantity |
|---|---|
| Call-out service and one hour of labour | 1 |
| Thread sealant for temporary valve repair | 1 |
Photos
